Applications

• Pharmaceutical
• Biosafety and Containment
• Anterooms
• Isolation Areas
• Vivariums
• Cleanrooms
• Containment Areas
• Laboratories
• Research and Development

Construction

• Cold rolled steel or aluminum enclosure
• Die-formed, TIG and spot welded
• Durable TGIC polyester powder coating featuring a 5-stage pre-treatment for superior adhesion and corrosion protection
• Available in White or Antimicrobial White Paint that inhibits growth of bacteria on the fixture surface
• Tested to 1,000 hours salt spray with 92% reflectance
• Closed-cell gasket completely seals the doorframe and the housing

Optics/LEDs

• Clear or diffused lens for uniform LED diffusion
• Lumen packages from 2,000 to 13,000 lumens
• 2700K, 3000K, 3500K, 4000K, 5000K CCT
• CRI ≥ 82, optional 90 CRI (Option: 90)
• Efficacy up to 165 lumens per watt
• L70 > 100,000 hours

Installation

• Recessed grid mounting
• Recessed design fits most standard T-bar grid ceilings

Electrical

• Universal 120/277VAC, 50/60Hz
• 0-10V Dimming driver
• Power Factor ≥ 0.90
• 347-480VAC option (Option: HVS)

Testing & Compliance

• cETL Listed for Wet Locations
• IP65 Rated
• ISO 5 Certified
• Buy American Act compliant
• Build America, Buy America Act compliant
• IC Rated
• Operating temperatures: -30°C to 50°C (-22°F to 122°F)

Warranty

• Five Year Warranty (Terms and Conditions Apply)
