Prescott 1 Series Single Phase, Indoor, Online Uninterruptible Power Supply
Prescott 1 Series Single Phase, Indoor, Online Uninterruptible Power Supply


Prescott 1 Series Single Phase, Indoor, Online Uninterruptible Power Supply

Spec Sheet Request More Info

The Prescott 1 is a freestanding, single phase, on-line, double conversion Uninterruptible Power Supply (UPS) utilizing advanced DSP/PWM technology to deliver conditioned, uninterrupted AC power. Each system consists of a solid-state inverter, rectifier/battery charger, static bypass switch, internal maintenance bypass switch, sealed maintenance-free battery plant, and a microprocessor-based status and control system with advanced diagnostics and monitoring.

Buy American Act Build America Buy America Warranty
Prescott 1 Specification
Prescott 1 Series Single Phase, Indoor, Online Uninterruptible Power Supply

Prescott 1 Series Single Phase, Indoor, Online Uninterruptible Power Supply

IES Files


Accessories - Factory Installed

EBW#
Extended Battery Warranty (# - Specify Number of Years)
ECM120/#
120V Environmental Control Module / Qty
ECM277/#
277V Environmental Control Module / Qty
EMB
External Maintenance Bypass Switch
EPO
Emergency Power Off
EW
Extended Warranty
FCON
Form C Contacts
NOF/V/#
Normally OFF Output Circuit / Voltage / Qty
NOH/V/#
Normally OFF “Hold ON” / Voltage / Qty
OCB/V/#/A
Output Circuit Breakers / Voltage / Qty / Amps
OST
Onsite Start-Up
RP
Remote Indicator Panel
SC
Service Contract
SNMP
SNMP Card
SRB
Seismic Rated Bracket

Contact us or your sales rep if you need a part number that isn't listed here.


Enter your zip code to find a representative in your area.


exitronix trace lite specialty led growlite

New
Prescott 1 Series Single Phase, Indoor, Online Uninterruptible Power Supply
Prescott 1 Series Single Phase, Indoor, Online Uninterruptible Power Supply


Prescott 1 Single Phase, Indoor, Online Uninterruptible Power Supply

The Prescott 1 is a freestanding, single phase, on-line, double conversion Uninterruptible Power Supply (UPS) utilizing advanced DSP/PWM technology to deliver conditioned, uninterrupted AC power. Each system consists of a solid-state inverter, rectifier/battery charger, static bypass switch, internal maintenance bypass switch, sealed maintenance-free battery plant, and a microprocessor-based status and control system with advanced diagnostics and monitoring.

Buy American Act Build America Buy America Warranty

Need more information?

We are happy to answer any questions you have about the Prescott 1 Series Single Phase, Indoor, Online Uninterruptible Power Supply.

Spec Sheet Request More Info

Configure your Prescott 1 Series Single Phase, Indoor, Online Uninterruptible Power Supply

Series
Power Rating
Voltage (Input-Output)
Run Time

Features

Applications

  • Data centers and IT infrastructure
  • Industrial and manufacturing environments
  • Water and wastewater facilities
  • Transportation and infrastructure
  • Energy and utility sectors
  • Telecommunications systems
  • Security and life safety systems
  • Storm shelter backup power applications

Features & Benefits

  • Power Rating: 3kVA-18kVA, 2KW-12.6KW
  • Input Voltage: 120, 208, 240, 277 or 480 VAC
  • Output Voltage: 120, 277, 480, 120/240 or 120/277 VAC
  • Surge Protection: The unit will protect itself and the load against surges defined in ANSI/EEE C62.45 category A/B
  • Battery: Sealed maintenance-free (AGM) lead calcium
  • Recharge Current: 10 Times discharge
  • Conforms to UL 924 and 1778
  • Operating Temperature: 0º to 40ºC (32º to 104ºF)

Configure your Prescott 1 Series Single Phase, Indoor, Online Uninterruptible Power Supply

Series
Power Rating
Voltage (Input-Output)
Run Time

Features

Applications

  • Data centers and IT infrastructure
  • Industrial and manufacturing environments
  • Water and wastewater facilities
  • Transportation and infrastructure
  • Energy and utility sectors
  • Telecommunications systems
  • Security and life safety systems
  • Storm shelter backup power applications

Features & Benefits

  • Power Rating: 3kVA-18kVA, 2KW-12.6KW
  • Input Voltage: 120, 208, 240, 277 or 480 VAC
  • Output Voltage: 120, 277, 480, 120/240 or 120/277 VAC
  • Surge Protection: The unit will protect itself and the load against surges defined in ANSI/EEE C62.45 category A/B
  • Battery: Sealed maintenance-free (AGM) lead calcium
  • Recharge Current: 10 Times discharge
  • Conforms to UL 924 and 1778
  • Operating Temperature: 0º to 40ºC (32º to 104ºF)
Prescott 1 Series Single Phase, Indoor, Online Uninterruptible Power Supply
Prescott 1 Specification
EBW#
Extended Battery Warranty (# - Specify Number of Years)

ECM120/#
120V Environmental Control Module / Qty

ECM277/#
277V Environmental Control Module / Qty

EMB
External Maintenance Bypass Switch

EPO
Emergency Power Off

EW
Extended Warranty

FCON
Form C Contacts

NOF/V/#
Normally OFF Output Circuit / Voltage / Qty

NOH/V/#
Normally OFF “Hold ON” / Voltage / Qty

OCB/V/#/A
Output Circuit Breakers / Voltage / Qty / Amps

OST
Onsite Start-Up

RP
Remote Indicator Panel

SC
Service Contract

SNMP
SNMP Card

SRB
Seismic Rated Bracket
